Micro Wave Oven Backlit Membrane Switch Silk Screen Printing

Micro Wave Oven Backlit Membrane Switch Silk Screen Printing

Description:

1) Membrane Switch with windows

2) Silicone keypad

3) Silk Screen Printing

4)perfect exterior

5) Over 1 million life cycles

Material

Material : PET /PC
Adhesive: 3M467 & 3M468 or as per request
High life time :>1million times

Pass:ISO9001:2008 RoHS.SGS
High quality

Commercial terms:

MOQ: 150pcs

Payment Terms: T/T or L/C

Mold Charge: 100% in Advance

Sample Time: 9-10 days after drawing approval.

Lead Time for production: 15-22 days after sample approval

The main technical parameters of membrane switch

1.Contact resistance: ＜1Ω /cm
2.Insulation resistance: ＜100MΩ (250V DC)
3.operating voltage: ≤ 50VDC
4.working current: 25- 100mA,0-30V DC
5.reliability, service life:＜1 million times
6.operating temperature: -40 ℃ ~ +70 ℃
7.Operating humidity:when40°C,＜98%RH

Applications:

Our membrane switches are widely used in:

• Medical Equipment
• Telecommunications apparatus
• Telephone systems
• Household appliances
• Security systems
• Industrial controls

Specifications:

Company Advantage:

1. Top managers are experienced in the same field for many years.
2. Professional staff and workers.
3. Strong R&D cabability
4. Quick Delivery
5. Competitive price
6. Two factories are available for large orders
7. Expert sales team and good customer service.
